AMPLIFIED PRESSURE TRANSDUCER - TABER 2911 Series
Lượt xem : 20
| Descriptions: |
Taber’s Model 2911 amplified, highly configurable pressure transducer series incorporates a rugged, hermetically sealed, stainless steel construction. Electronic components permit the integration of noise filtering, voltage regulation and signal conditioning. The bonded foil strain gage diaphragm design provides outstanding accuracy, stable signal fidelity over time and is compatible with a wide variety of gas and liquid media. Taber’s 2911 series is available for broad pressure ranges with pressure reference options. Specifications: - Output Signal: 0-5 VDC | 4-20 mA - Full Scale Output (FSO): 5 VDC | 16 mA - Static Error Band: ± 0.25% FSO using Best Fit Straight Line (BFSL) and Root Sum Squared (RSS) Method - Total Error Band: ± 1% FSO over entire Compensated Temperature Range (CTR) - Maximum Expected Operating Pressure (MEOP): 1.4 BAR through 2,068 BAR (2 PSI through 30,000 PSI) - Proof Pressure: 1.5 times MEOP, Minimum - Minimum Burst Pressure: 2 times MEOP - Compensated Temperature Range (CTR): Temperature range in which the transducer will operate within the total error band. -34° C to +77° C (-30° F to +170° F) - Operating Temperature: Temperature range in which the transducer will operate without degradation of performance once it returns to the CTR. -54° C to +121° C (-65° F to +250° F) - Strain Gage Type: Resisted Bonded Foil - Insulation Resistance: > 100 MOhm at 50 VDC - Electrical Connection: MS3449H10B6P per MIL-DTL-26482 Series 2 - Mating Connector (not included): MS3476-10-6S or equivalent - Excitation Voltage: 20-36 VDC (28 VDC nominal) | 8-36 VDC (24 VDC nominal) - Operating Current: < 20 mA | N/A - Wetted Ports Materials: 304L, 304L VAR, 316L, 347, 15-5 PH, 17-4 PH, A286 - Weight: Typical 130 g to 164 g - Case Material: 304, 17-4 PH - Pressure Port: AS4395-04 (MS33656-4) 4375-20 UNJF-3A flared male thread ... |
| Accessories: |
N/A
|
| Optional Accessories: |
Platinum RTD outputs: 100 Ohm, 1000 Ohm and 2000 Ohm.
|
| Standard Features: |
Voltage (VDC) or Current (mA) output signal Does not require regulated power supply Wide pressure range Output short circuit protected Improved accuracy options Optional Bulkhead filtering for EMI/EMC environments Optional isolated or non-Isolated electronics Improved signal transmission over long cable distances when using Current (mA) output signal High reliability components available PSI, Bar or MPa in absolute, gauge or vented pressure options |
